Automatic Tube Filling And Sealing Machine For Inner Heating Type Toothpaste for cosmetic
Detail Descriptions
It is designed for aluminum tube and metal soft tube filling and sealing . It’s widely used in pharmacy, cosmetic and chemical industries.
Working process:
Manually put the metal tubes (max. 16 tubes) into the tube-holding base, the second-station for color-line marking detection. The third station is filling and then come to the tail bending station for folding, clamping, batch number printing and at last finished products discharging. Every tube should go through the whole procedure and then finished after filling and crimping .
Change angular potion of each tube by means of mechanical transmission. Photoelectric device is used to detect the position of tube and if there is any tube in right position, then filling system starts to fill the tube with fixed quantity. The tube is sealed by cam, which is steady, safe and with no air leaving. It can also achieve number/batch printed on the end, finally the tube is ejected.
Features:
1. The machine, with a controllable filling volume or quantity, is featured with a reliable performance.
2. The machine is suitable for the filling of metallic tubes of any type because the tube-holding base can be easily replaced in purpose.
3. A perfect and reliable sealing can be reached.
4. The parts which touch material are made of stainless steel 304.(SUS316 is option)
Specification:
1. Power Supply: AC220V±10% 50HZ, single phase(can be customized)
2. Filling Quantity: 5-50 ml
3. Quantity Error: ± 1%
4. Motor power: 0.75~1.1 kw
5. Compressed Air: pressure0.6~0.7Mpa Volume: 0.2m³/min
6. Capacity: 10~40tube/min (adjustable)
7. Dimension: 1000mm×600mm×1700mm
8. Weight: 480kg
Packaging & shipping specifications
FAQ
1. What products can this PE tube filling and sealing machine handle?
This machine is suitable for compatible toothpaste, lotion, facial cleanser, cosmetic cream, gel, ointment and other liquid or paste products packed in PE or plastic soft tubes.
2. What types of tubes are suitable for this machine?
It is mainly designed for compatible PE tubes, plastic cosmetic tubes and other heat-sealable soft tubes. Actual tube material should be confirmed before ordering.
3. Is this machine suitable for toothpaste filling?
Yes. Compatible toothpaste and similar viscous paste products can be filled when the filling system and nozzle are matched to the product viscosity.
4. Can it fill lotion and cosmetic cream?
Yes. It can be used for compatible lotion, facial cream, hand cream, cleansing cream and cosmetic gel.
5. Can it fill facial cleanser?
Yes. Facial cleanser is a typical application for this type of plastic tube filling and sealing equipment.
